A two-sided floor-to-ceiling wine display kit pairing a 10-foot Vino Series Post with 40 mounting plates and cork-forward Vino Rails pegs, holding 40, 80, or 120 standard bottles depending on width.
Key Features
- Includes one Vino Series Post, 10 ft long and cut to fit on site, for floor-to-ceiling installations up to 12 ft
- Ships with 40 Vino Rails Mounting Plates plus 40, 80, or 120 sets of Vino Rails depending on capacity selected
- Capacity by width: 40 bottles single-wide (4-1/2 in), 80 double-wide (8 in), 120 triple-wide (13 in)
- Overall height 122 in (310 cm) maximum and 28 in (72 cm) deep, with bottles displayed on two sides of the post
- Mounting plates install at any vertical interval of 5 in (13 cm) or greater, and on one, two, three, or four sides of the post
- Built from high-quality aluminum pegs and commercial-grade steel framing, backed by a lifetime warranty
- BILT Apps 3D interactive installation instructions are included in the kit
Fits & Works With
Part of the VintageView Vino Series. This is the Vino Rails (cork-forward) version of the Vino Series Post system, so it uses Vino Rails pegs and Vino Rails Mounting Plates, not the label-forward Vino Pins hardware of the companion Vino Pins Post Kit. It mounts between floor and ceiling rather than to a wall, so it needs no wall backing or backer board and suits glass walls, stone or tile faces, and room dividers. The 10 ft post is field-cut to the actual ceiling height, and the floor and ceiling anchors appropriate to the building’s substrate are supplied by the installer, not included in the kit. Additional Vino Rails and Vino Post Plates can be added later for more capacity.
Specifications
| Bottle Capacity | 40, 80, or 120 standard 750ml bottles (two-sided configuration) |
|---|---|
| Width | 4-1/2 in (12 cm) single-wide, 8 in (20 cm) double-wide, 13 in (33 cm) triple-wide |
| Height | 122 in (310 cm) maximum; post supplied at 10 ft and cut to fit on site |
| Depth | 28 in (72 cm) |
| Material | High-quality aluminum (Vino Rails pegs) and commercial-grade steel (Vino Series Post frame) |
| Finish Options, Post | Matte black, gloss black, golden bronze, gunmetal |
| Finish Options, Vino Rails | Aluminum, gloss black, golden bronze, gunmetal |
| Kit Contents | 1 x Vino Series Post (10 ft, cut to fit on site), 40 Vino Rails Mounting Plates, 40/80/120 sets of Vino Rails, BILT 3D interactive instructions |
| Vertical Spacing | Any interval of 5 in (13 cm) or greater |
| Mounting | Floor-to-ceiling post; floor and ceiling anchors vary by substrate and are installer-supplied |
| Manufacturer SKU | VR-FCP-KIT-11-K |
| Warranty | Lifetime warranty |
