Our 100 Amp MPPT Solar Charge Controller has an efficient MPPT algorithm, MPPT efficiency ≥99.5% and converter efficiency up to 98%.
Four types of load mode selection: ON/OFF, PV voltage control, Dual Time control, PV+ Time control.
Charge mode: Three stages (constant current, constant voltage, floating charge), it prolongs service life of the batteries. 12V / 24V / 36V / 48V battery system voltage automatic recognition. Rs-485 communication protocol.
Key Specifications:
- MPPT Solar Charge Controller Model: CM-100A
- Max Charge Current: 100A
- System Voltage: 12V/24V/48V Auto. sensing
- Max PV Voltage(Voc): 150Vdc
- Solar Operating Voltage: 12V @ 18-150Vdc 24V @ 34-150Vdc 48V @ 65-150Vdc
- Max PV Input Power: 12V @ 1350W 24V @ 2750W 48V @ 5400W
- Battery Type: VRLA/Gel/Liquid/Li-ion
- Operation Temperature: -20~+40℃
- Net Weight: 17.6 pounds
- Gross Weight: 19.4 pounds
